PRIMA p. 17
MOVABLE SPOT WELDER
This machine complies with the 89/392/CEE directives and subsequent modifications and
supplements.
MICROCAR-28 (SPOTTER): SPARE PARTS.
1 90019533 HANDLE
2 20010104 SPOTTER COVER
3 20010106 WELDING CONTROL PANEL
4 20010110 CUPPER CONNECTION
5 90019359 CONNECTING PLUG
6 90019310 FEET
7 20010103 SPOTTER BASIS
8 20010105 WELDING TRANSFORMER
9 90014029 ELECTRIC COIL
10 90019532 TAP FOR TOOLS CONTROL
11 90019037 CABLE HOLDER
12 90010146 FUSE HOLDER (315 mA.)
13 90018002 DIODE SCR
14 90014020 ELECTRONIC BOARD
15 90019368 ON-OFF SWITCH
16 90010080 BOARD TRANSFORMER
17 90018003 CABLE BUSHING
18 90018004 CONTROL SELECTION REGULATOR
