Introduction
2
TECHNICAL SPECIFICATION
Output power per channel 2 x 100W into 8Ω, 2 x 180W into 4Ω
Speaker terminals 4 –16Ω
Output impedance <0.06Ω
DC offset <3mV
Balanced inputs 560mV
Line inputs 280mV
Tape outputs 280mV
Frequency response <10Hz – 100kHz, -3dB
THD <0.07% at full power
Signal-to-noise, line -100dB (A-weighted)
Mains 100/115/230V
Power consumption 600W max
Peak current ±40A
Dimensions (WxDxH) 430 x 375 x 100mm
Weight 15.5kg
