Totally analogue design.
Direct-coupled signal path with a DC-servo to
remove any DC offset.
Low-hum R-core audiophile mains transformer.
Relay-controlled mute circuit for silent on/off
switching.
Type
2 RCA
Impedance
100Ω
Type
2 RCA
Impedance
Switchable: 10Ω, 20Ω, 50Ω, 100Ω, 200Ω, 500Ω
or 47kΩ
Gain
MM 41.5dB, MM with jumper 46.5dB, MC 62dB
THD+N
MM <0.02%, MC <0.05%
Signal to noise ratio
20Hz – 20kHz unweighted
MM -70dB, MC -60dB
Power supply
100V ±10%, 120V ±10%, or 230V ±10%
depending on region.
Power consumption
Operation: 11.5W
Size
430 x 380 x 95mm (WxDxH)
Weight
8.5kg
Colour
Black or titanium
For use with a very low output moving-magnet
cartridge, the R32 can be adjusted to give an
additional 5dB increase in gain.
•
Switch off the R32 and disconnect the mains
cable.
•
Unscrew the screws on the lid of the R32,
using an Allen key, and lift off the cover.
•
Move the jumpers so they short the links in
positions JP101 and JP1 on the circuit board:
