Primax EASY LINE - Technical Specifications and Data Plates

14
1.4. GENERAL TECHNICAL DATA PLATE ELECTRIC AND GAS OVENS
IPkPa
Voltage
Matricola - Serial N° Modello - Model
kW max A maxHz
Predisp. gas - Gas type Pin
Voltage
0051-10
kW max
Matricola - Serial N° Modello - Model Type
Cat Gas G20 G25 G30 G31
I2E
p (mbar)
20 - - - LU PL
I3B/P
p (mbar)
- - 30 30 IS MT HU
II2H3+
p (mbar)
20 - 28-30 37 AL CY GR IE
II2H3+
p (mbar)
20 - 28-30 37 IT LT PT GB
II2H3+
p (mbar)
20 - 28-30 37 CZ MK SK SI
II2H3+
p (mbar)
20 - 28-30 37 ES CH TR
II2H3B/P
p (mbar)
20 - 30 30 AL BG CY HR
II2H3B/P
p (mbar)
20 - 30 30 DK EE FI GR
II2H3B/P
p (mbar)
20 - 30 30 LV LT NO MK
II2H3B/P
p (mbar)
20 - 30 30 RO SK SI SE
II2H3B/P
p (mbar)
20 - 30 30 TR
II2H3B/P
p (mbar)
20 - 50 50 AT SK CH
II2E+3+
p (mbar)
20 25 28-30 37 BE FR
II2E3B/P
p (mbar)
20 - 30 30 RO
II2ELL3B/P
p (mbar)
20 20 50 50 DE
II2L3B/P
p (mbar)
- 20 30 30 RO
II2L3B/P
p (mbar)
- 25 30 30 NL
Hz ΣQn (kW) (kg/h) (m3/h)
GAS DATA PLATE
G20 20 mbar G30 28-30 mbar G31 37 mbar
WARNINGS
QUESTO APPARECCHIO DEVE ESSERE INSTALLATO IN CONFORMITA’
ALLE NORMATIVE VIGENTI E USATO SOLO IN LOCALI BEN VENTILATI
LEGGERE LE ISTRUZIONI PRIMA DELL’INSTALLAZIONE ED USO DELL’ APPARECCHIO
IT
2. GENERAL TECHNICAL FEATURES
ELECTRIC MODELS
EXTERNAL DIM.
(WxDxH)
(mm)
INTERNAL DIM.
(WxDxH)
(mm)
CAPACITY
(Kw)
TOTAL
POWER
(Kw)
PACKED
VOLUME
(m3)
GROSS
WEIGHT
(kg)
CONVECTION
ECE-805-HS
760x640x700
500x370x450
5
2/3 GN , 440x350
3,35
3,5
230V 1N 50Hz
0,51
78
ECE-905-HS
920x690x700
660x420x450
5
GN 1/1, 400x600
5,5
5,7
400V 3N 50Hz
0,66
88
ECE-907-HS
920x690x850
660x420x600
7
GN 1/1, 400x600
9
9,3
400V 3N 50Hz
0,78
98
ECE-910-HS
920x690x1075
660x420x825
10
GN 1/1, 400x600
13,5
13,95
400V 3N 50Hz
0,93
120
CONVECTION
HUMIDIFICATION
EUE-805-HS
760x710x700
500x370x450
5
2/3 GN , 440x350
3,35
3,5
400V 3N 50Hz
0,51
80
EUE-905-HS
920x760x700
660x420x450
5
GN 1/1, 400x600
5,5
5,7
400V 3N 50Hz
0,66
90
EUE-907-HS
920x760x850
660x420x600
7
GN 1/1, 400x600
9
9,3
400V 3N 50Hz
0,78
100
EUE-910-HS
920x760x1075
660x420x825
10
GN 1/1, 400x600
13,5
13,95
400V 3N 50Hz
0,93
122
CONVECTION
STEAM
EDE-805-HS
760x710x700
500x370x450
5
2/3 GN , 440x350
3,35
3,5
230V 1N 50Hz
0,51
80
EDE-905-HS
920x760x700
660x420x450
5
GN 1/1, 400x600
5,5
5,7
400V 3N 50Hz
0,66
90
EDE-907-HS
920x760x850
660x420x600
7
GN 1/1, 400x600
9
9,3
400V 3N 50Hz
0,78
100
EDE-910-HS
920x760x1075
660x420x825
10
GN 1/1, 400x600
13,5
13,95
400V 3N 50Hz
0,93
122
