Limits
Function
Left
Display
Right
Display
(Factory Default
Values)
Comments
Burn Back 0.10 0.00-1.00SBURN/BACK
Wire Sharp ON ON-OFFWIRE/SHRP
SPOT OFF OFF-ONSPOT
Spot Time 2.0 0.1-20.0SSPOT/TIME
Stitch OFF OFF-ONSTCH
Stitch Time 2.0S 0.2-4.0SSTCH/TIME
Dwell Time 0.5S 0.1-1.0SDWEL/TIME
Wire Feed
Speed Units
IPM MPM-IPMWFS/UNIT
Restore Factory
Defaults
NO NO-YESFACT/DFLT
Arc Hour
Accumulated
Runtime
0.0 0.0-9999.9HR
The time difference between turning the wire
feed OFF and the voltage is turned OFF.
Wire Sharp adds a burst of current at the end
of a weld to remove the ball at the end of the
wire. This improves the restart of the next weld.
Spot is used to weld two thin plates together at
a desired location by melting the top & bottom
plates together to form a nugget between
them. The weld time is set by the Spot Time.
Spot Time is the time used for the Spot weld
mode.
Stitch is used to weld two or more components
by stitch or interval weld together. The weld
time is set by the Stitch Time and the non weld
time is set by the Dwell Time.
Stitch Time is the time used for the weld time
in Stitch weld mode.
Dwell Time is the time used for the non weld
time in Stitch weld mode.
IPM provides preview wirespeed in Inches Per
Minute. MPM provides preview wirespeed in
Metres Per Minute.
Long press advanced features selector for 3
seconds to enter into menu mode, press
advance features selector to choose Factory
default setting, rotate volts knob to choose yes
or no, and press MIG/LIFT TIG/STICKER selector
to confirm yes or no. When YES is selected all
the user adjustable values in this table (except
Arc Hour Accumulated Runtime) are reset to
the Factory Default Values.
Provides Arc On Hours that the power source
has welded. The number displayed is in hours
and read only. It will rollover to 0 once 10,000
hours have been reached.
