Primus MB16 - User Manual

136 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

INDUSTRIAL WASHER EXTRACTORS

HIGH SPIN WASHER EXTRACTORS:

6 kg 33 kg

7 kg 40 kg

10 kg 55 kg

16 kg 120 kg

22 kg

RIGID MOUNTED WASHER EXTRACTORS:

6 kg 18 kg

7 kg 22 kg

10 kg 27 kg

13 kg 35 kg

16 kg 43 kg

HIGH SPIN HYGIENIC BARRIER WASHER EXTRACTORS:

16 kg 66 kg

26 kg 90 kg

33 kg 140 kg

44 kg 180 kg

PROGRAMMING MANUAL

FULL CONTROL

100962 G

Publication date: 24 Jun 2008

SELECT PROGRAM

ABCDEFGHKLMNOPQR

100521

Table of Contents

Questions and Answers

P
Patrick EllisAug 19, 2025
How to fix a Primus MB16 Scrubber with a display that won't light up?
- D
  Danielle AndersonAug 19, 2025
  If the display of your Primus Scrubber is not illuminated when you switch on the power, consider the following: * Ensure the external power supply is switched on and providing power to the machine. * Deactivate the emergency button. * Check and properly connect the power connector on the board, ensuring correct wiring. * Inspect the fuse on the electronic board; replace it if burned. Also, verify that input signals or the +16Vdc Supply Signal are not touching the cabinet. * If there's no EPROM on the electronic board, install the correct EPROM with the software.
J
Jamie GuerreroAug 21, 2025
What to do if my Primus MB16 keyboard buttons aren't working?
- D
  dennis32Aug 21, 2025
  If your Primus Scrubber is not responding when you press the keyboard buttons, here are some things to check: * Make sure the input connector “A” is securely connected and inspect the wiring between the connector and the key-switch. * Ensure the key switch is set to “Run mode.” * Verify that the connector “K” of the keyboard is properly connected.
C
Christina HarrisonAug 23, 2025
How to improve the display brightness on a Primus MB16?
- A
  Audrey SmithAug 25, 2025
  If the display on your Primus Scrubber is illuminated but hard to read, adjust the brightness setting in the Configuration Menu until the display is clear and bright.
C
christine62Aug 26, 2025
Why is the drum not turning in my Primus MB16?
- K
  Kathy MaldonadoAug 26, 2025
  If the drum in your Primus Scrubber isn't turning and no error message is displayed, check the following: * Inspect the belt for any breaks and check its tension; replace or adjust as needed. * Check the motor voltage applied. * Assess whether the motor is still functional. * Check the inverter.
S
Shelley MccarthyAug 28, 2025
How to resolve a 'Heating Failure' error on a Primus Scrubber?
- S
  Stacy SavageAug 28, 2025
  If you're encountering a 'Heating Failure' (Failure 13) error on your Primus Scrubber, check if the heating contactor is activated. If it's not, repair the wiring or replace the contactor.
T
Tracy MorrisAug 30, 2025
What causes outputs to not activate when starting a program on a Primus MB16?
- M
  Mark HarveyAug 30, 2025
  If you start a program on your Primus Scrubber, but the outputs aren't activating, ensure that connectors “R” and “Q” are correctly connected and not inverted. Pin “Q10” must be supplied with 220Vac when the door is closed.
C
Courtney HernandezSep 1, 2025
How do I fix a wrong water level issue on my Primus MB16 Scrubber?
- R
  ronald57Sep 1, 2025
  If you're experiencing a wrong water level issue with your Primus Scrubber, make sure the programmed water levels are correct and that the right machine type is selected in the Configuration Menu. You can reinitialize standard water levels by programming new values or reloading the Standard Wash programs.
M
millerchristopherSep 3, 2025
What should I do if my Primus Scrubber shows an 'Overfill Failure'?
- P
  pnguyenSep 3, 2025
  If your Primus Scrubber displays an 'Overfill Failure' (Failure 12), the water inlet valves might be broken. Try cleaning or replacing the water inlet valve diaphragms.
A
Amanda CamposSep 5, 2025
How to troubleshoot a 'Fill Failure' on a Primus Scrubber?
- S
  Steven WhiteSep 6, 2025
  If you're facing a 'Fill Failure' (Failure 11) on your Primus Scrubber, start by checking if the external water valves are open. If they are closed, open the water inlet valves to allow water to flow into the machine.
S
Sabrina KnightSep 8, 2025
What to do if my Primus Scrubber displays a 'Too Hot' error?
- J
  jasonbarnesSep 8, 2025
  If your Primus Scrubber shows a 'Too Hot' (Failure 15) error, verify that the correct water inlet valves have been programmed. Ensure you're programming both hot and cold water inlet valves for the wash sequence.

Summary

Warnings and Symbols

Warnings

Crucial safety warnings and precautions for operating the washing machine.

Basic Description of Controls

Creating a Wash Program

Explains the step-by-step process of creating a new wash program.

Programming Functions

Covers programming limits, water temperature, and inlet valve selection.

Initializing the Machine

Initialization Menu Guide

Step-by-step instructions on how to access and navigate the Initialization Menu.

Configuration Menu Setup

Guide to setting up machine-specific parameters in the Configuration Menu.

Programming Wash Programs

Program Menu Navigation

How to enter and use the Program Menu for managing wash programs.

Program Functions and Editing

Details on giving programs names, viewing, editing, copying, and deleting programs.

Program Step Functions

How to add, edit, insert, view, and delete individual steps within a wash program.

Programming Wash Sequences

Steps for selecting and programming wash sequences like Prewash, Wash, and Rinse.

Programming Drain and Extraction Sequences

Operation Menu Guide

Starting Up and Loading Machine

Managing Wash Cycles

Handling Failures and Power Interruptions

Troubleshooting and Error Handling

Display and Fault Messages

Handling Common Faults and Failures

Failure Overview and Diagnosis

Service Menu and Diagnostics

Problem Checklists and Error Explanations

Primus MB16 Specifications

General

Brand	Primus
Model	MB16
Category	Scrubber
Language	English
