INDUSTRIAL WASHER EXTRACTORS
HIGH SPIN WASHER EXTRACTORS:
6 kg 33 kg
7 kg 40 kg
10 kg 55 kg
16 kg 120 kg
22 kg
RIGID MOUNTED WASHER EXTRACTORS:
6 kg 18 kg
7 kg 22 kg
10 kg 27 kg
13 kg 35 kg
16 kg 43 kg
HIGH SPIN HYGIENIC BARRIER WASHER EXTRACTORS:
16 kg 66 kg
26 kg 90 kg
33 kg 140 kg
44 kg 180 kg
PROGRAMMING MANUAL
FULL CONTROL
100962 G
Publication date: 24 Jun 2008
SELECT PROGRAM
ABCDEFGHKLMNOPQR
100521

Table of Contents

Questions and Answers

  • T
    tmaldonadoAug 19, 2025
    How to fix a Primus FF10 Scrubber with a display that won't light up?
    • B
      Benjamin HopkinsSep 12, 2025
      If the display of your Primus Scrubber is not illuminated when you switch on the power, consider the following: * Ensure the external power supply is switched on and providing power to the machine. * Deactivate the emergency button. * Check and properly connect the power connector on the board, ensuring correct wiring. * Inspect the fuse on the electronic board; replace it if burned. Also, verify that input signals or the +16Vdc Supply Signal are not touching the cabinet. * If there's no EPROM on the electronic board, install the correct EPROM with the software.
  • A
    aguirreangelaAug 21, 2025
    What to do if my Primus Scrubber keyboard buttons aren't working?
    • M
      Michael MartinezAug 21, 2025
      If your Primus Scrubber is not responding when you press the keyboard buttons, here are some things to check: * Make sure the input connector “A” is securely connected and inspect the wiring between the connector and the key-switch. * Ensure the key switch is set to “Run mode.” * Verify that the connector “K” of the keyboard is properly connected.
  • X
    xonealAug 25, 2025
    How to improve the display brightness on a Primus Scrubber?
    • S
      Shaun DanielsAug 25, 2025
      If the display on your Primus Scrubber is illuminated but hard to read, adjust the brightness setting in the Configuration Menu until the display is clear and bright.
  • D
    Dr. Jennifer Levy MDAug 26, 2025
    Why is the drum not turning in my Primus FF10 Scrubber?
    • S
      Sharon GarciaAug 26, 2025
      If the drum in your Primus Scrubber isn't turning and no error message is displayed, check the following: * Inspect the belt for any breaks and check its tension; replace or adjust as needed. * Check the motor voltage applied. * Assess whether the motor is still functional. * Check the inverter.
  • M
    Michael OconnellAug 27, 2025
    How to resolve a 'Heating Failure' error on a Primus FF10?
    • C
      Chase GrantAug 28, 2025
      If you're encountering a 'Heating Failure' (Failure 13) error on your Primus Scrubber, check if the heating contactor is activated. If it's not, repair the wiring or replace the contactor.
  • J
    John ThomasAug 30, 2025
    What causes outputs to not activate when starting a program on a Primus FF10?
    • U
      uweberAug 30, 2025
      If you start a program on your Primus Scrubber, but the outputs aren't activating, ensure that connectors “R” and “Q” are correctly connected and not inverted. Pin “Q10” must be supplied with 220Vac when the door is closed.
  • E
    Erika SimmonsSep 1, 2025
    How do I fix a wrong water level issue on my Primus Scrubber?
    • M
      Matthew SmithSep 1, 2025
      If you're experiencing a wrong water level issue with your Primus Scrubber, make sure the programmed water levels are correct and that the right machine type is selected in the Configuration Menu. You can reinitialize standard water levels by programming new values or reloading the Standard Wash programs.
  • D
    Dawn KnightSep 3, 2025
    What should I do if my Primus FF10 Scrubber shows an 'Overfill Failure'?
    • R
      rhonda82Sep 3, 2025
      If your Primus Scrubber displays an 'Overfill Failure' (Failure 12), the water inlet valves might be broken. Try cleaning or replacing the water inlet valve diaphragms.
  • C
    Christie BarberSep 5, 2025
    How to troubleshoot a 'Fill Failure' on a Primus FF10 Scrubber?
    • S
      sarahwhiteSep 5, 2025
      If you're facing a 'Fill Failure' (Failure 11) on your Primus Scrubber, start by checking if the external water valves are open. If they are closed, open the water inlet valves to allow water to flow into the machine.
  • J
    John LopezSep 7, 2025
    What to do if my Primus Scrubber displays a 'Too Hot' error?
    • R
      Robert PerezSep 7, 2025
      If your Primus Scrubber shows a 'Too Hot' (Failure 15) error, verify that the correct water inlet valves have been programmed. Ensure you're programming both hot and cold water inlet valves for the wash sequence.

Summary

Warnings and Symbols

General Warnings

General safety warnings before operating the programmer and machine.

Main Menu Navigation

Initialisation Menu

Program Menu

Configuration Menu

Basic Description of Controls

Specific Menu Functions

Details the purpose of Program, Configuration, Initialization, Service, and Diagnostic menus.

Washing Program Creation

Machine Types and Wash Sequence Programming

Differentiates programming for top/front hopper types and wash sequences.

Programming Functions

Water Temperature and Inlet Valve Programming

Programming Functions (Continued)

Wash, Extraction Speed, Supplies, and Time Limits

Initializing the Machine

Initialisation Menu Access

Steps to access and navigate the initialization menu for basic setup.

Configuration Menu

Accessing the Configuration Menu

Procedure to enter the configuration menu, including password entry.

Programming

General Programming Overview

Overview of functions for complete programs and program steps.

Step 1: Program Menu

Accessing and navigating the main program menu for wash programs.

Step 2: Program Functions

Program Number, Name, View, Edit, and Copy

How to manage wash programs: select, name, view, edit, and copy.

Step 3: Program Step Function

Managing Program Steps

Step 4: Programming the Wash Part

Selecting Wash Part Sequences

Guide to choosing wash sequences like Prewash, Wash, Rinse, etc.

Step 5: Programming the Drain Step

Selecting Drain;Extraction Steps

Choosing between Drain, Extract, Low Extract, High Extract, No Drain, Static Drain.

The Drain Sequence

Operation Menu

6.1. Starting Up the Machine

Initial steps before starting a wash cycle, including installation checks.

6.2. Switching On Power

6.3. Loading the Washing Machine

6.4. Putting Soap into the Soap Hopper

6.5. Starting a Wash Program

Steps to select and initiate a wash program.

Programming a Delay Time

Setting a Delayed Start Time

Power Interruptions and Special Buttons

Handling Power Interruptions

Special Function Buttons Overview

Pre-Programmed Programs

7.1. Legend and Program Types

7.2. Standard Wash Programs

Lists and details 15 standard wash programs, like Hot Wash, Warm Wash, etc.

Troubleshooting

Display and Fault Messages

Describes common display messages and how fault messages are presented.

Fault Message Interpretation

Explains the components of a fault message and their meaning.

Handling Fault Messages

Overruling and Erasing Faults

Methods to override or clear fault messages and safety conditions.

Interpreting Too Hot and Water in Cage

Explains specific fault messages related to temperature and water level.

Overview of Failure Messages

Failure Code Diagnosis and Action

Service Menu Access

Navigating the Service Menu

Viewing and Erasing Fault Messages

Diagnostic Program

Accessing and Running the Diagnostic Program

Test Sequence Descriptions

Top Soap Hopper Test Sequences

Front Soap Hopper Test Sequences

Problem Check List

Troubleshooting Common Machine Issues

Explanation Error Messages

Drain and Balance Failure Explanations

Service Information

9.1. Routine Maintenance

9.2. Information for Service

9.3. Programmer Electronic Board

9.4. Replacing Electronic Board and Keypad

Step-by-step guide for replacing the electronic board and keypad.

9.5. Installing New Software

Instructions for updating the machine's software via EPROM replacement.

Specification of Your Machine

Machine Data and Electronic Specifications

Details on machine type, serial number, voltage, programmer type, and memory.

Configuration and Initialization Data

Lists configurable settings for machine operation and initialization.
