102 PROGRAMMING MANUAL 100962 G PUBLICATION DATE 24 JUN 2008.DOC
T TEST SEQUENCE
Display test and door lock test
Sensor test
Motor test
Water fill, heating and drain test
BASIC Diagnostic Wash program
T Diagnostic Test Sequence for Machines with Top Soap Hopper.
Test (R) : For Rigid Mounted washing machines.
Test (F) : For Free Standing washing machines.
Test
(R)
Test
(F)
Info Explanation
1 1
Black display followed
by a Text display.
£ Door lock test (locks and unlocks 5 x the door)
£ Display test
*** ***
None £ Sensor test (all wash machine sensors are
tested)
3 3
Reverse £ Wash speed (inverse direction high spin)
4 4
Stop
⇒ Standstill motor
5 5
Forward £ Wash speed (same direction high spin)
6 6
Distribution £ Distribution speed (same direction high spin)
7 7
Low spin £ Low spin speed (same direction high spin)
8
High spin £ High spin speed
(the drum is turning away from the soap box)
8 9
Stop £ Free run or controlled deceleration
20 20
I1 £ The machine takes water by inlet 1
21 21
Drain 1 £ The water is drained by drain valve 1
22 22
I2 £ The machine takes water by inlet 2 until the
safety level for heating is reached
£ Heating activated (only if Wait temp = on)
23 23
Drain 1 (2)* £ The water is drained by drain valve 1
24 24
I3 £ The machine takes water by inlet 3
25 25
Drain 1 £ The water is drained by drain valve 1
26 26
I4 £ The machine takes water by inlet 4
27 27
Drain 1 £ The water is drained by drain valve 1
28 28
I5 £ The machine takes water by inlet 5
29 29
Drain 1 £ The water is drained by drain valve 1
32 30
I6 £ The machine takes water by inlet 6
31 31
Drain 1 £ The water is drained by drain valve 1
50 50
Tumble
⇒ The tumble sequence
Unload
⇒ End of the Diagnostic Cycle
Note : * The second drain valve will be opened if a second drain valve has been selected in the
Configuration menu.
*** No number 2 is displayed at the sensor test as this takes only a fraction of a second.
