124 PROGRAMMING MANUAL 100962 G PUBLICATION DATE 24 JUN 2008.DOC
FAILURE 300-353: MITSUBISHI INVERTER ALARM MESSAGE
If a Mitsubishi Inverter Alarm occurs, check the trouble shooting in the Mitsubishi inverter manual.
300 Err OC1 308 Err FAN 316 Err RET 324 Err OP2 332 Err MB5 340 Err E.3 348 USB
301 Err OC2 309 Err OLT 317 Err CPU 325 Err OP3 333 Err MB6 341 Err ILF 349 OS
302 Err OC3 310 Err BE 318 Err E.6 326 Err CTE 334 Err MB7 342 Err PTC 350 OD
303 Err OV1 311 Err GF 319 Err E.7 327 Err P24 335 Err FIN 343 Err PE2 351 EP
304 Err OV2 312 Err OHT 320 Err IPF 328 Err MB1 336 Err OSD 344 Err CDO 352 E.11
305 Err OV3 313 Err OPT 321 Err UVT 329 Err MB2 337 Err ECT 345 Err IOH 353 E.13
306 Err THT 314 Err PE 322 Err LF 330 Err MB3 338 Err E.1 346 Err SER
307 Err THM 315 Err PUE 323 Err OP1 331 Err MB4 339 Err E.2 347 Err AIE
DIAGNOSE FOR FAILURE 300-301-302: OC-ERRORS
1. Check if there is no short circuit on the
output of the inverter. (loose wire of motor
cable,…)
Repair the short circuit.
2. Check if there is no short circuit in the
Terminal Box of the motor. (loose wire of
the motor cable, screws or other metal
pieces who can move inside the terminal
box.)
Repair the short circuit.
Make sure the screws are sufficiently tightened.
DIAGNOSE FOR FAILURE 303-304-305 : OV-ERRORS
If there is too much regenerative energy coming from the motor (working as a generator) to the inverter, the
voltage on the capacitors will become too high and the inverter goes into OV-alarm state.
1. Check if the correct machine type is
selected in the S-submenu
If the wrong machine type is selected, enter the right
machine type
2. Check if there was a high unbalance during
extraction, which can be caused by putting
only half loads in the machine.
Put always a full load in the machine drum.
Do not put other material than textile linen (fabrics) in
the machine.
3. Check if the fault is persistent If the fault is persistent, contact the manufacturer
DIAGNOSE FOR FAILURE 306: THT-ERROR
If the output current of the inverter is abnormal high for some time, the inverter will go into THT-alarm
state.
1. Check if the power supply is sufficient high
and stable during extraction with load.
Repair the power supply.
2. Check if the drum rotates normally by hand.
(no abnormal high friction)
Repair / clean what is necessary.
3. Check if the correct machine type is selected in
the S-Menu.
If the wrong machine type is selected, enter the right
machine type.
4. Check if the correct parameters have been
loaded in the inverter.
If the correct parameters are not loaded in the inverter,
load the correct parameters.
DIAGNOSE FOR FAILURE 307: THM-ERROR
If the motor current is higher than allowed for a longer time, the inverter will active the electronic
overcurrent protection to prevent the motor from overheating and the inverter will go into THM-alarm state.
1. Check if the drum rotates normally by hand.
(no abnormal high friction)
Repair / clean what is necessary.
To Next Page
