ELECTRICAL INSTALLATION
ELECTRICAL INSTALLATION
The washing machine must be connected using
a permanently installed cable through an isola-
ting switch by a qualified electrician.
Power supply
The machine is supplied, depending on market,
for one of the following supplies (see rating
plate):
A. 3-phase, 400V, 50 Hz supply, 10 A.
B. Single-phase, 230 V, 50 Hz supply, 13/16 A.
C. Single-phase, 230 V, 50 Hz supply, 10 A.
If an earth leakage circuit breaker is fitted it
must be of type A.
Reconfiguration
The machine can be reconfigured The machine
should be reconfigured as shown in the wiring
diagram underneath the top panel of the mach-
ine.
NOTE!
Electrical connection /reconfiguring must be
carried out by a qualified electrician.
ELECTRICAL INSTALLATION WASHING MACHINE
CONNECTING TO A COIN MECHANISM
Connection to a coin mechanism must be car-
ried out by a qualified electrician.
A special connecting cable is required to con-
nect the machine to a coin mechanism.
Recommendations for choice of coin mechanism
The connecting cable supplies the coin mecha-
nism with power (230 V). The coin mechanism
must be able to short-circuit two signal leads
for a period of time (around 0–10 minutes).
This is so that the user has time to load the
laundry, select the programme and start the pro-
gramme after inserting the coins.
