Primus PW 5 - Electrical Installation; Connecting to Coin Mechanism

30
ELECTRICAL INSTALLATION
The washing machine must be connected using
a permanently installed cable through an isola-
ting switch by a qualified electrician.
Power supply
The machine is supplied, depending on market,
for one of the following supplies (see rating
plate):
A. 3-phase, 400V 50Hz supply 10A, heating
power 2620/2500W.
B. Single-phase, 230V 50Hz supply 13/16A,
heating power 2620/2500W.
C. Single-phase, 230V 50Hz supply 10A, hea-
ting power 1900W.
If an earth leakage circuit breaker is fitted it
must be of type A.
Reconfiguration
The machine can be reconfigured The machi-
ne should be reconfigured as shown in the wi-
ring diagram underneath the top panel of the
machine.
NOTE!
Electrical connection /reconfiguring must be
carried out by a qualified electrician.
Connecting the tumble dryer and the washing
machine together
Wiring the two machines together as described
below must be carried out by a qualified elec-
trician.
To ensure a uniform load on the phases when
installing a 3-phase tumble dryer together with
a washing machine for 3-phase operation the
phases should be connected as follows:
Tumble dryer:
Terminal marked L1 to phase 1.
Terminal marked L2 to phase 2.
Terminal marked L3 to phase 3.
Washing machine:
Terminal marked L1 to phase 1.
Terminal marked L2 to phase 2.
Terminal marked L3 to phase 3.
CONNECTING TO A COIN MECHANISM
Connection to a coin mechanism must be car-
ried out by a qualified electrician.
The coin mechanism must be connected bet-
ween the tumble dryer’s power lead and the
wall socket.
ELECTRICAL INSTALLATION
TUMBLE DRYER ELECTRICAL INSTALLATION
NOTE!
The drying time is longer for Single-phase, 230V
50Hz supply 10A, heating power 1900W.
