WASHING MACHINE MECHANICAL INSTALLATION
MECHANICAL INSTALLATION
TRANSIT SCREWS
Before the machine can be used the three trans-
it screws must be removed as described below.
Each transit screw has a washer and a rubber
spacer. The rubber
spacers are used to
protect the screw ho-
les after the screws
have been removed.
1. First unscrew the screw and remove the was-
her.
2. Then pull out the rubber spacer.
2
1
3. Finally, refit the rubber spacers to cover the
transit holes.
