TECHNICAL INFORMATION
TECHNICAL DATA
Height: 850 mm.
Width: 595 mm.
Depth: 585 mm.
Weight: 39 kg (vented) / 47 kg (condenser).
Drum capacity: 111 l.
Drying capacity: 5.0 kg.
Speed: 52 rpm.
Power rating: See rating plate.
Composition of drum: Stainless steel.
Composition of casing: Powder-painted and hot-dip galvanized sheet
steel or stainless steel.
Installation: Stacked, free-standing or built-in.
Drain (condenser tumble dryer): 2.0 m EPDM rubber hose.
Vent hose (venting tumble dryer): 3.0 m PVC.
TECHNICAL INFORMATION TUMBLE DRYER
P1 Extra dry
P2 Dry
P3 Normal dry
P4 Iron dry
P5 Extra dry
P6 Dry
P7 Normal dry
P8 Iron dry
Temperature
Drying
Cooling
Length (appr. min)
The length of the drying depends on the moisture of the items being dried. The time for drying shown in the table
above indicates the relative time for each programme.
Normal
Normal
Normal
Normal
Low
Low
Low
Low
20
20
20
20
20
20
20
20
PROGRAMME CYCLES
