27
11. Unscrew the arrowed screw. If the dryer is a
condenser model you must
also open the cover over the
condenser.
12. Now fit the door to the right side of the
machine.
7. Lift out the door magnet (1) and plate (2).
8. Refit the door magnet where the plate was.
9. Refit the plate where the magnet was.
10. Screw in the screws to secure the door mag-
net and plate.
MECHANICAL INSTALLATION TUMBLE DRYER
1
2
1
2
