Print-Rite PR-855 - 2.1.2 Paper Printing Area; 2.1.3 Usage of the Printing Paper

8
2)
Chain paper
Width 3in-10.5in
Length Min 5.5in/Min 139.7mm
Paper weight
Single paper
52-82 g/
㎡
Multi-layer paper
40-52 g/
㎡（
per layer
）
Paper thickness
Single paper 0.07-0.11mm
Multi-layer paper
0.07-1.2mm
（
Thickness of multi-layer
）
2.1.2 Paper Printing Area
 Printing area is the range of data showed on the paper, normally not all the paper.
Fig. 2-1
Note: Users can customize the headspace by EDS settings, more information please see chapter
4.
 Actual printing area
The maximum of paper width is 11.7 inch, and the maximum of printing width is 8.5 inch.
2.1.3 Usage of the Printing Paper
 Usage of chain paper
When you use chain print paper, please note the paper loading position.
Please install the chain paper according to the middle one in Fig. 2-2, or the paper will be
separated from the chain paper clips.
Fig. 2-2
Fig. 2-3
