Specifications
52
Interface Specifications
Serial Interface COM1
Serial Interface COM2
USB Interface
Ethernet Interface
NOTE: GP-4201TW does not have an Ethernet interface.
GP-4201T GP-4201TW GP-4203T
Asynchronous
Transmission
RS-232C / RS-422 /
RS-485
RS-232C RS-485 (isolation)
Data Length 7 or 8 bits
Stop Bit 1 or 2 bits
Parity None, odd or even
Data Transmission
Speed
2,400...115,200 bps,
187,500 bps (MPI)
2,400...115,200 bps 2,400...115,200
bps, 187,500 bps
(MPI)
Connector D-Sub 9 pin (plug) D-Sub 9 pin
(socket)
GP-4201TW
Asynchronous Transmission RS-422 / RS-485
Data Length 7 or 8 bits
Stop Bit 1 or 2 bits
Parity None, odd or even
Data Transmission Speed 2,400...115,200 bps,
187,500 bps (MPI)
Connector D-Sub 9 pin (plug)
USB (Type A) Interface USB (mini-B) Interface
Connector USB 2.0 (Type A) x 1 USB 2.0 (mini-B) x 1
Power Supply Voltage 5 Vdc ±5% -
Maximum Current
Supplied
500 mA -
Maximum Transmission
Distance
5 m (16.4 ft)
GP-4201T / GP-4203T
Ethernet (LAN) IEEE802.3i / IEEE802.3u,
10BASE-T/100BASE-TX
Connector Modular jack (RJ45) x 1
