GP4000 Series Hardware Manual
93
Dimensions
NOTE:
z If you are using the rear mount model, refer to Dimensions (see page 184).
External Dimensions
1 Front
2 Right Side
3 Top
173
218
204
60
5
159
2.36
8.03
8.58
6.81
6.26
0.20
mm
in.
(1) (2)
(3)
(GP-4401T)
