178
B Serial Interface (COM1) RS-232C Serial Interface. Connector: D-Sub 9
pin (plug) x 1.
C Serial Interface (COM2) RS-422/485 Serial Interface. Connector: D-
Sub 9 pin (plug) x 1.
D Power Plug Connector -
E
SD Card Access LED
This lamp lights up when SD Card is inserted.
( see page 181)
NOTE: Do not remove or insert the SD Card
when the LED lamp is on. Doing so may
damage data on the SD Card.
F SD Card Interface
Cover/Replacement Battery
Insertion Cover
For information on how to open the cover, and
insert or remove the SD Card, refer to SD Card
Insertion / Removal (see page 150).
For information on how to open the cover and
replace the battery, refer to Replacing the
Primary Battery (see page 168).
G USB (mini-B) Interface Conforms to USB2.0 (mini-B) x 1.
Communication Distance: 5 m (16.4 ft) or less.
H
Ethernet Interface
Ethernet transmission interface (10BASE-
T/100BASE-TX)
Connector: Modular jack (RJ-45) x 1. ( see
page 181)
I Maintenance LED ( see page 181)
Part Name Description
To Next Page
