Specifications
98
Electrical Specifications
DC Model AC Model
Power Supply
Rated Input Voltage 24 Vdc 100...240 Vac
Input Voltage Limits 19.2...28.8 Vdc 85...264 Vac
Rated Frequency - 50/60 Hz
Rated Frequency Range - 47...63 Hz
Voltage Drop 10 ms or less 1 cycle or less (Voltage
drop interval must be 1
second or more)
Power Consumption 17 W or less 100 Vac: 44 VA or less
240 Vac: 58 VA or less
When power is not
supplied to external
devices
12 W or less 100 Vac: 30 VA or less
240 Vac: 44 VA or less
Backlight OFF (Standby
Mode)
7 W or less 100 Vac: 18 VA or less
240 Vac: 29 VA or less
Backlight Dimmed
(Brightness: 20%)
8 W or less 100 Vac: 22 VA or less
240 Vac: 31 VA or less
In-Rush Current 30 A or less
Voltage Endurance 1,000 Vac, 20 mA for 1
minute (between
charging and FG
terminals)
1,500 Vac, 20 mA for 1
minute (between
charging and FG
terminals)
Insulation Resistance 500 Vdc, 10 MΩ or more (between charging and
FG terminals)
