GP4000 Series Hardware Manual
65
Electrical Specifications
Power Supply
Rated Input Voltage 24 Vdc
Input Voltage Limits 19.2...28.8 Vdc
Voltage Drop 5 ms or less
Power Consumption 10.5 W or less
When power is not supplied to
external devices
6.5 W or less
Backlight OFF (Standby Mode) 4.5 W or less
Backlight Dimmed (Brightness:
20%)
5W or less
In-Rush Current 30 A or less
Voltage Endurance 1,000 Vac, 20 mA for 1 minute
(between charging and FG
terminals)
Insulation Resistance 500 Vdc, 10 MΩ or more
(between charging and FG
terminals)
To Next Page
