GP4000 Series Hardware Manual
89
Interface Specifications
Serial Interface COM1
Serial Interface COM2
USB Interface
Ethernet Interface
SD Card Interface
SD Card slot x 1 (maximum 32 GB SD/SDHC Card)
Asynchronous Transmission RS-232C
Data Length 7 or 8 bits
Stop Bit 1 or 2 bits
Parity None, odd or even
Data Transmission Speed 2,400...115,200 bps
Connector D-Sub 9 pin (plug)
Asynchronous Transmission RS-422 / RS-485
Data Length 7 or 8 bits
Stop Bit 1 or 2 bits
Parity None, odd or even
Data Transmission Speed 2,400...115,200 bps,
187,500 bps (MPI)
Connector D-Sub 9 pin (plug)
USB (Type A) Interface USB (mini-B) Interface
Connector USB 2.0 (Type A) x 1 USB 2.0 (mini-B) x 1
Power Supply Voltage 5 Vdc ±5% -
Maximum Current
Supplied
500 mA -
Maximum Transmission
Distance
5 m (16.4 ft)
Ethernet (LAN) IEEE802.3i / IEEE802.3u,
10BASE-T/100BASE-TX
Connector Modular jack (RJ45) x 1
