Connectivity
24
RUN Mode Peripherals - COM2: RS-485 (isolation)
NOTE: For instructions on how to connect to other devices, always refer to the “GP-
Pro EX Device/PLC Connection Manual”.
RUN Mode Peripherals - Ethernet Communication
GP unit
Host Controller
PLC etc.
Serial Interface (COM2: RS-485 (isolation) mode)
PROFIBUS Cable
(Prepared by user)
RS-485 Cable
(Prepared by user)
MPI Cable
CA3-MPI-PG1-PFE
CA3-MPI-PGN-PFE
RS-485 (isolation) Port
RS-485 (isolation) Port
RS-485 (isolation) Port
GP unit
Ethernet Interface
(10BASE-T/100BASE-TX)
Twisted Pair Cable
(commercial type)
Hub
(commercial type)
To an Ethernet Network
