IMPORTANT
・ In the [Question] dialog box, be sure to select [Yes] and specify the destination
folder. If you select [No], images will not be called correctly.
・ GP-4301T/TW that is a replacement model is not equipped with a CF card slot.
If a destination folder is created in the work above, the CF card setting will be
replaced with the SD card setting automatically.
To check or change the destination folder setting, see [5.1 Changing the setting
of the external media to use].
3.5 Change the Display Unit Type
(* Only when replacing GP-2300L with GP-4301TW)
Open the project file (*.prx) on GP-Pro EX that is converted in the Chapter 3.4 and
change the display unit type to GP-4301TW.
(1) Open the converted project file (*.prx) on GP-Pro EX.
(2) Click [System Settings]->[Display]->[Change Display] in [Project] menu and
change the Display Unit type to “GP-4301TW”.
(3) Click [Project]->[Save] or [Save As] to save the change.
38/59
