Interface names
GP-3500S/L ST-3501C GP-4501TW
1
Power Input Terminal Block (AC) /
Power Connector (DC)
Power Connector (DC)
2 Serial I/F (COM1)
3 Serial I/F (COM2)
4 Ethernet I/F - Ethernet I/F
5 USB I/F (Type A)
6 - USB I/F (Type mini B)
7 - SD Card I/F
8 CF Card I/F -
2.2 Touch Panel specifications (only when replacing with GP-4501T)
For replacing GP3500/ST3500 series with GP-4501T, you can select the Matrix type
(2-point touch input at the same time same as GP2000 Series) or the Analog type
(1-point touch input) for Touch Panel Type.
For the Analog type, even if you touch two points at the same time, touch input of the
coordinates located between those two points is recognized. Take note of it.
There’s a model number difference between the Analog type and the Matrix type. For
details, see GP4000 Series Model Number
.
2.3 Display Colors
The display type of GP-3500L and ST-3501C (when using a monochrome mode) is a
monochrome LCD, but GP-4501T/TW has a TFT color LCD. After replacement, the
black and white display changes to the color one.
When the setting of the display unit type is changed from a monochrome model to a
color one on GP-Pro EX, the data may be displayed in colors except black and white
depending on a setting. After changing the display unit type, please confirm the
display colors of the drawing or the parts on the screens just in case.
