Chapter 3 Replacement Procedure

3.1 Work Flow

Installation Screen Communication

Check the compatibility of

hardware in Chapter 2.

Receive screen data from

GP/ST-3500 series. *1

Remove GP3000/ST3000

series.

Install GP-4501T/TW.

Connect the power cord.

Check the performance

and start operation.

Change the received data

on GP-Pro EX.

Check and modify the

data on GP-Pro EX.

Transfer the screen

data to GP-4501T/TW.

Check the connection

between GP-4501T/TW

and a PLC in the GP-Pro

EX Device/PLC

Connection Manual.

Connect GP-4501T/TW

and PLC with the PLC’s

cable.

Start connection and

check the communi-

cation.

*1: This step is required if screen data is saved only in the GP unit, not in any other device.
