Chapter 2 Specifications
2-15
Input (DIN0, 1, 2, 3 and RST)
Output (DOUT0, 1, 2, 3)
INPUT VOLTAGE RANGE DC12V to 24V
INPUT CURRENT Lower than or equal to10mA
INNER RESISTOR 3.6k Ω 1/10W
INSULATION Greater than or equal to 500V
SINK SOURCE INPUT Correspondence
OUTPUT VOLTAGE RANGE DC24V
OUTPUT CURRENT Lower than or equal to 120mA
INSULATION Greater than or equal to 500V
PROTECTION DIODE Equipped
• For further details of the circuit diagram, refer to the following.
SEE
7.1.1 RAS Features (page7-2)
