Pro-face PL-6930-T41 - Dimensions; PL-6930 External Dimensions

PL-6930 / PL-7930 Series User Manual
2-16
2.4 Dimensions
2.4.1 PL-6930 External Dimensions
Unit: mm [in.]
 Dimensions with installation fasteners
330[12.99]
346[13.62]
287[11.30]
13[0.51]
170[6.69]
271[10.67]
Top
Side
Front
236[9.29]
342[13.46]
352[13.86]
293[11.54]
10[0.39]
264[10.39]
8[0.31]
5[0.20]
283[11.14]
Top
Front
Side
Bottom
Side
