Pro-face PL-6930-T41 - PL-7931 External Dimensions

Chapter 2 Specifications
2-19
2.4.4 PL-7931 External Dimensions
Unit: mm [in.]
 Dimensions with installation fasteners
374[14.72]
325[12.80]
359[14.13]
13[0.51]
134[5.28]
310[12.20]
Top
Front
Side
381[15.00]
332[13.07]
26[1.02]
120[4.72]108[4.25]
11[0.43]
264[10.39]
371[14.61]
30[1.18]
142[5.59] 147[5.79]
24[0.94]
120[4.72]108[4.25]
322[13.07]
Bottom
Top
Front
SideSide
