PL-6930 / PL-7930 Series User Manual
4-6
(3) Insert each of the fasteners shown below.
Be sure to pull the fastener back until it is
flush with the rear of the attachment hole.
(4) Use a Phillips screwdriver to tighten each
fastener screw and secure the PL in place.
• Tightening the screws with too much force can damage the PL unit’s plastic case.
• For the moisture resistance effect, the torque required to tighten these screws is 0.5
N
•m.
