11
12
77
15
14
49
49
Avoid pinching the
Main Wire (77)
13
13. Slide the Console Cover (16) upward against the
Handlebar (14). Attach the Console Cover with
two M4 x 16mm Screws (49).
14
49
16
12. While a second person holds the Console (15)
near the Handlebar (14), plug the Main Wire
(77) into the receptacle on the Console. Tip:
The wire connector should slide in easily
and snap into place with an audible click. If it
does not, turn the connector and try again.
Then, insert the excess wire into the
Handlebar (14).
Tip: Avoid pinching the Main Wire (77). Attach
the Console (15) to the Handlebar (14) with four
M4 x 16mm Screws (49); start all the Screws,
and then tighten them.
To Next Page
