7
1
. Make sure that the power cord is unplugged.
W
ith the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (57) so that the treadmill is more stable;
do not fully fold the Frame yet.
Cut the shipping tie securing the Wire Harness
(92) to the Base (99). Next, locate a tie in the in-
dicated hole in the Base, and use the tie to pull
the Wire Harness out of the hole. See the inset
drawing. Cut off the end of the tie.
57
99
1
92
Hole
2. Attach two Base Feet (93) to the Base (99) in
the locations shown with two M4.2 x 25mm Tek
Screws (2) and two Base Foot Spacers (94).
Attach the other two Base Feet (93) with two
M4.2 x 25mm Tek Screws (2).
99
2
93
2
93
2
2
93
2
93
94
94
92
Tie
Cut
To Next Page
