PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see
whether it has been preassembled. Extra parts may be included.
M10 x 90mm Carriage Bolt (50)–4
M10 Washer
(22)–10
M10 Locknut
(15)–20
M8 Locknut
(54)–2
M12 Locknut
(16)–1
M6 Washer
(25)–1
Large Washer (55)–2
M8 x 65mm Bolt (52)–2
M6 x 10mm
Screw (35)–2
M10 x 70mm Bolt/Screw (51)–12
M10 x 65mm Carriage Bolt (26)–2
M6 x 25mm
Screw (20)–8
M6 x 70mm Screw (24)–1
