14
14. Attach the Curl Bar (38) to the Leg Lever (26)
with the Curl Bar Pin (54).
Then, attach the tether (H) on the Curl Bar Pin
(54) to the Leg Lever (26) with an M4 x 19mm
Screw (18).
14
38
26
54
H
18
13. Insert the Long Pad Tube (57) into the bracket
(G) on the Front Leg (25). Then, slide two Foam
Pads (43) onto the Long Pad Tube, and press
two Pad Caps (44) into the Long Pad Tube.
Attach the two Short Pad Tubes (42) and the
remaining Foam Pads (43) and Pad Caps (44)
to the Leg Lever (26) in the same way.
13
43
43
43
43
44
44
44
26
25
57
42
42
G
43
44
