12
52
101
101
50, 51
10. Attach the Front Cover (52) to the Left and Right
Shields (50, 51) with six M4 x 16mm Flat Head
Screws (101); start all the Flat Head Screws,
and then tighten them.
10
118
11
11. Plug the Power Adapter (118) into the receptacle
on the front of the trainer.
Note: To plug the Power Adapter (118) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 13.
12. Make sure that all parts are properly tightened. Extra parts may be included. Place a mat beneath the
trainer to protect the floor.
