Pro-Form PFEX78918.0 - Part Identification Chart

6
M8 Split
Washer (56)–2
M8 Curved
Washer (24)–6
M8 Acorn
Nut (25)–4
M8 x 50mm Carriage
Bolt (64)–4
M4 x 25mm
Screw (71)–1
M8 x 35mm Screw
(65)–2
M8 Locknut
(15)–3
M8 Washer
(70)–3
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part. The number following the key number is the quantity needed for assem-
bly. Note: If a part is not in the hardware kit, check to see if it has been preassembled. Extra parts may be
included.
