10
37
38
5
8
46
52
58
46
52
9. Attach the Right Pedal Leg (38) to the Right
Upper Body Leg (37) with an M10 x 20mm
Button Screw (58), a Small Axle Cover (46), and
a
n M10 x 25mm Washer (52).
A
ttach the Right Link Arm (39) to the right Crank
Arm (31) with an M10 x 20mm Button Screw
(58), a Small Axle Cover (46), and an M10 x
25mm Washer (52).
Repeat this step for the other side of the
elliptical exerciser.
9
31
10. Tighten the two M8 x 16mm Button Screws (53)
and the two M8 x 35mm Button Screws (80) in
the Frame (1).
Locate the two M4 x 19mm Screws (75) in the
sides of the Upright (3). Slide the Water Bottle
Holder (6) against the Upright and downward
onto the two Screws. Then, tighten the Screws.
10
6
75
53
80
39
75
3
1
