6
7
76
2
1
9
9
2
65
53
54
2
1
2. Insert the Track (2) into the Frame (1). Attach
the Track with two M8 x 50mm Button Screws
(65), two M8 x 16mm Button Screws (53), and
two M8 x 25mm Washers (54). Do not tighten
the Button Screws yet.
1.
Tip: It may be easier to do this step if you
l
oosen the two Leveling Feet (9) at the rear
of the Track (2).
Orient the Track Cover (7) and the Track (2) as
shown. Attach the Track Cover to the Track with
four M4 x 50mm Screws (76).
To make assembly easier, read the
information on page 5 before you begin.
