Pro-Line System CS300 User Manual

EN
CS 300 Gate Controls / Rev.D 5.6 – 17
SYSTEM
Pro-Line
DIAGNOSIS
Scroll up through menu:
+
> 2 sec.
Scroll down through menu:
-
> 2 sec.
Return to AUTOMATIC:
P
Only queries are possible
UPPERSWITCH ON LOWERSWITCH ON UP SWITCH OFF PR.INPUT OFF DOWN SWITCH OFF SKS ON IMP. INPUT OFF SWITCH CLK OFF LIGHT BARR. ON STOP CIRCUIT ON CYCLE 000000 AWG 0000
AUTOMATIC STANDBY
P
>1 sec.
ADJUSTMENT STANDBY
+
-> Position DOOR OPEN
ADJUSTMENT MAIN UP
Save door position:
P
Keep pressed and
+
>1 sec.
-
-> Position DOOR CLOSED
ADJUSTMENT MAIN DOWN
Save door position:
P
Keep pressed and
-
>1 sec.
P
>1 sec.
INPUT
+
and
-
> 2 sec.
INPUT DEUTSCH
Scroll up through menu:
+
> 2 sec.
Scroll down through menu:
-
> 2 sec.
Select value:
P
>1 sec.
Increase value:
+
Decrease value:
-
Save value:
P
Return to INPUT:
+
and
-
> 1 sec.
RUNTIME 60
P
>1 sec.
OPEN TIME 0 PREWARNING 0 REVERS.TIME 0.3 M1-3 STAND. Mod1 QUICK CLOSE OFF RELAY 1 Mod6 RELAY 2 Mod7 RELAY 3 Mod1 RELAY 4 Mod14 SKS CHECK OFF DELAY UP OFF FINE-UP UPPERSWITCH FINE-DOWN LOWERSWITCH S-POINT1 4050 S- POINT2 3950
DIRECTION R REVERSPOINT 50 POWER 10 AUTO LEVEL OFF P/E BARR POINT 300 PRESS/REL MOD1 PR.INPUT MOD1 P/E BAR CLOSE MOD1 P/E BAR OPEN MOD2 SKS LEADING MOD1
