Pro-Line System CS300 - Product overview; Versions and housing options

4 – CS 300 Gate Controls / Rev.D 5.6
SYSTEM
Pro-Line
4.1 Versions
The following package options are available for the CS 300
control:
− CS 300 control with LCD monitor
− CS 300 control with LCD monitor in housing
− CS 300 control with LED module for setting the OPEN end
position and the CLOSED end position
(no other settings are possible)
− CS 300 control without LED module and without LCD
monitor (module or monitor is needed for settings)
Alltheaboveversionscanbettedwithaplug-inweekly
timer and a plug-in radio receiver.
The following options are available for the housing:
− Housing unit with 3-button input unit CS
− Housing unit with 3-button input unit KDT
− Housing with ON/OFF key switch
− Housing with main switch
− Housing with emergency stop switch
These operating instructions describe the different connection
options and the programming of variants:
− CS 300 control with LED module
− CS 300 control with LCD monitor
− Software version 5.6 B
Low voltage
− DIN EN 60335-1 (Household and similar electrical
appliances - Safety - Part 1: General requirements)
− DIN EN 60335-2-103 (Household and similar electrical
appliances - Safety - Part 2-103: Particular requirements for
drives for gates, doors and windows)
Committee for Workplaces (Ausschuss für Arbeitsstätten -
ASTA)
− ASR A1.7 (Technical Regulations for workplaces - Doors
and gates)
