8. Navigator (LCD monitor only)
AUTOMATIC STANDBY
P
>1 sec.
ADJUSTMENT STANDBY
+
-> Position DOOR OPEN
ADJUSTMENT MAIN UP
Save door position:
P
Keep pressed and
+
>1 sec.
-
-> Position DOOR CLOSED
ADJUSTMENT MAIN DOWN
Save door position:
P
Keep pressed and
-
>1 sec.
P
>1 sec.
INPUT
+
and
-
> 2 sec.
INPUT DEUTSCH
Scroll up through menu:
+
> 2 sec.
Scroll down through menu:
-
> 2 sec.
Select value:
P
>1 sec.
Increase value:
+
Decrease value:
-
Save value:
P
Return to INPUT:
+
and
-
> 1 sec.
RUNTIME 60
P
>1 sec.
OPEN TIME 0 PREWARNING 0 REVERS.TIME 0.3 M1-3 STAND. Mod1 QUICK CLOSE OFF RELAY 1 Mod6 RELAY 2 Mod7 RELAY 3 Mod1 RELAY 4 Mod14 SKS CHECK OFF DELAY UP OFF FINE-UP UPPERSWITCH FINE-DOWN LOWERSWITCH S-POINT1 4050 S- POINT2 3950
DIRECTION R REVERSPOINT 50 POWER 10 AUTO LEVEL OFF P/E BARR POINT 300 PRESS/REL MOD1 PR.INPUT MOD1 P/E BAR CLOSE MOD1 P/E BAR OPEN MOD2 SKS LEADING MOD1
