9.3 Diagnostic operating mode
Display Meaning Status
UPPERSWITCH OPEN end position OFF: End position reached
ON: End position not reached
LOWERSWITCH CLOSED end position OFF: End position reached
ON: End position not reached
OPEN BUTTON Command button / OPEN input ON: Button activated / input is active
OFF: Button not activated / input not active
PR.INPUT Programmable input 1 (X4 / 9 +10) ON: Input active
OFF: Input not active
CLOSE BUTTON Command button / CLOSE input ON: Button activated / input is active
OFF: Button not activated / input not active
SKS Closing edge safety device
(PSswitch,8.2kΩoroptosensor)
or light curtain (optosensor)
(X4 / 5-8) CLOSING direction
ON: System closed
OFF: System interrupted (fault)
IMPULS Command button / IMP. INPUT input
(X3 / 7+8)
ON: Button activated / input is active
OFF: Button not activated / input not active
SWITCH CLK Weekly timer (pluggable) ON: Timer activated
OFF: Timer not activated
LIGHT BARR. Drive through photocell (X4 / 1-4) ON: Photocell signal is OK
OFF: Light beam interrupted or fault in photocell
STOP CIRCUIT Safety circuit
Emergency stop systems of the door
system
ON: Safety circuit closed
OFF: Safety circuit interrupted
CYCLE Door cycle counter Displays number of door cycles counted so far
1 x OPEN + 1 x CLOSE = 1 cycle
Counts only if the travel cut-out points are reached.
AWG Shows position information of absolute
value encoder
Displays the current transmitted value
