Status Response
Page 12 AVP RS-232 Quick Guide
Packet 2
Main Zone Audio Source Number – Packet 2 shows the current source selected in
the main zone. The following table shows the hex value returned and the source
button it represents. The AVPs More inputs are represented but do not have an
associated front panel source button. A list of the more inputs programming should
be kept for reference.
Hex Returned
Input # Front Panel Button Label
01 1 VCR1
02 2 DISC1
03 3 VCR2/DISC2
04 4 TV/AUX
05 5 SAT
06 6 CD
07 7 TAPE
08 8 AUX
09 9 TUNER
0A MORE 1
NONE
0B MORE 2
NONE
0C MORE 3
NONE
0D MORE 4
NONE
0E MORE 5
NONE
0F MORE 6
NONE
10 MORE 7
NONE
11 MORE 8
NONE
Packet 3
Not Defined – Packet 3 is not defined and thus has no information on system status.
This packet will always return a 08h.
NOTE: The hex value of this packet is the hex value for a backspace. Due to this
certain programs will need to set up to ignore a backspace or the previous packet
will be eliminated from the response. Please refer to the manual for your RS-232
control system on how to turn off the backspace if needed.
Packet 4
Main Zone Video Input Number – Packet 4 shows the current video source of the
AVP. Sources that have a video input defined in setup will follow the table described
in packet 2 above. Sources with no video input defined will show a value of 82hfor
packet 4 indicating that the current source from packet 2 is audio only.
