Status Response
AVP RS-232 Quick Guide Page 13
Packet 5
Main Zone Volume – Packet 5 shows the absolute volume of the AVP main zone.
The table in Appendix A shows the hex value returned and the appropriate volume.
NOTE 1: The AVPs volume control does not track all numbers between 0 and max
volume. This includes no half-volume steps until 31.5. The table in appendix A
shows all volume settings of the AVP from 0 to 92 (factory setting for max volume).
NOTE 2: The AVP maybe setup to show the volume in a 0 db RELATIVE scale. The
relative volume setting requires looking at other information in the AVP that is not
available to the status request. To see what the relative volume is the front panel
ASCII information as described in Packets 16 to 27 will need to be used.
Packet 6
Remote Zone Audio Input – Packet 6 shows the current audio source for the
remote zone and follows the source table in packet 2. Please see packet 2 above.
Packet 7
Remote Zone Video Input – Packet 7 shows the current video source for the
remote zone and follows the same return as in packet 4. Please see packet 4 above.
Packet 8
Remote Zone Volume – Packet 8 shows the absolute volume of the AVP remote
zone just as packet 5 shows the main zone volume setting. Please see packet 5
above.
Packet 9
Current Application – The value of this packet shows the current type of digital
application. Analog signals will be 00h.
Hex Value Application Type
00 PCM
01 AC-3
03 DTS
05 MPEG
06 96k PCM
FF None (No Signal)
