21
ILLUSTRATED
PARTS BREAKDOWN
SSU320RHN-GB
SSU320RHL-GB
Key
No.
Part Number Description
QTY
SSU320RHN-GB
SSU320RHL-GB
1 SLU35A102-GB TOP 1
2 SLU35A130-GB DOOR WITH SCREEN 1
3 SLU35A106-GB ACCESS PANEL 1
4 SLU35A101C BACK 1
5 SLU35A103 LOUVER ASSEMBLY 1
6 SLU35A201 FIREBOX ASSEMBLY 1
7 SLU35A108 CABINET BOTTOM 1
8 SLU35A116 LOWER FRONT PANEL 1
9 SLU35A401 FIREBOX FLOOR 1
10 SLU35A132 DOOR HINGE 1
11 SLU35A131 DOOR HINGE 1
12 SLU35A105 SIDE 2
To Next Page
