www.usaprocom.com
31200068-01A
PARTS
MODELS WZ(N,L)18MVA, WZ(N,L)24MVA, WZ(N,L)30MVA
This list contains replaceable parts used in your heater. When ordering parts, follow the in-
structions listed under Replacement Parts on page 29 of this manual.
ITEM WZN18MVA WZN24MVA WZN30MVA DESCRIPTION QTY.
1 ** ** ** Grate Assembly 1
2 ** ** ** Burner Assembly 1
3 161816-01 161816-01 161816-01 ODS Assembly 1
4 ML083-03 ML083-03 ML083-03 Piezo Ignitor 1
5 ML073-03 ML073-03 ML073-03 Ignitor Cable 1
6 VL067-01 VL067-01 VL067-01 Switch 1
7 WZL008-01V WZL008-02V WZL008-03V Log Middle Bracket 1
8 WZL003-01 WZL003-02 WZL003-03 Log Rear Bracket 1
9 WZL002-01V WZL002-02V WZL002-03V Fixing Plate 1
10 MAL033-03 MAL033-03 MAL033-03 Knob Connector 2
11 MAL034-01 MAL034-01 MAL034-01 Knob Stem 2
12 MAL033-01 MAL033-01 MAL033-01 Control Knob 2
13 NRV82FB-3 NRV82FB-3 NRV82FB-3 Regulator 1
14 MAL027 MAL027 MAL027 Valve Connector 1
15 161814-01 161814-01 161814-01 Thermostat Valve Assy 1
16 WZL015-01 WZL015-02 WZL015-03 Log #1 1
17 WZL016-01 WZL016-02 WZL016-03 Log #2 1
18 WZL017-01 WZL017-02 WZL017-03 Log #3 1
19 WZL018-01 WZL018-02 WZL018-03 Log #4 1
20 WZL019-01 WZL019-02 WZL019-03 Log #5 1
21 WZL020-01 WZL020-02 WZL020-03 Log #6 1
** Not a eld replaceable part.
ITEM WZL18MVA WZL24MVA WZL30MVA DESCRIPTION QTY.
1 ** ** ** Grate Assembly 1
2 ** ** ** Burner Assembly 1
3 161817-01 161817-01 161817-01 ODS Assembly 1
4 ML083-03 ML083-03 ML083-03 Piezo Ignitor 1
5 ML073-03 ML073-03 ML073-03 Ignitor Cable 1
6 VL067-01 VL067-01 VL067-01 Switch 1
7 WZL008-01V WZL008-02V WZL008-03V Log Middle Bracket 1
8 WZL003-01 WZL003-02 WZL003-03 Log Rear Bracket 1
9 WZL002-01V WZL002-02V WZL002-03V Fixing Plate 1
10 MAL033-03 MAL033-03 MAL033-03 Knob Connector 2
11 MAL034-01 MAL034-01 MAL034-01 Knob Stem 2
12 MAL033-01 MAL033-01 MAL033-01 Control Knob 2
13 NRV82FB-3 NRV82FB-3 NRV82FB-3 Regulator 1
14 MAL027 MAL027 MAL027 Valve Connector 1
15 161815-01 161815-01 161815-01 Thermostat Valve Assy 1
16 WZL015-01 WZL015-02 WZL015-03 Log #1 1
17 WZL016-01 WZL016-02 WZL016-03 Log #2 1
18 WZL017-01 WZL017-02 WZL017-03 Log #3 1
19 WZL018-01 WZL018-02 WZL018-03 Log #4 1
20 WZL019-01 WZL019-02 WZL019-03 Log #5 1
21 WZL020-01 WZL020-02 WZL020-03 Log #6 1
