Note: The frequency band of your RDR3500
TM
or
RDR3600
TM
is marked on the radio label. If it is not visible,
identify the frequency band according to the color circle on
the antenna: white indicates UHF and red indicates VHF.
RCA RDR3500
TM
Overview
10
6
7
8
2
15
1
5
3
4
11
13
14
12
9
Push-to-Talk (PTT) Button
Side Button 1*
Side Button 2*
Side Button 3*
Microphone
On/Off/Volume Knob
Channel Knob
Top Button*
Antenna
LED Indicator
Accessories Connector
Battery Latch
Belt Clip
Battery
Speaker
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RDR3500
* These buttons are programmable by your
RCA Communications Systems Dealer only
upon request at the time of purchase.
