Prodys QUANTUM LITE - Page 61

Prodys S.L. Tel: +34 91 6896880  Fax: +34 91 6943777  Email: sales@prodys.net  Web: www.prodys.com
Page 61
INPUTS
Transparent
Under this configuration, the state of the input will be present in
its homologous output in the Quantum codec connected on the
other end. This allows the user to get remote contact closures, a
typical application in the broadcast market.
Program Call/Hang-Up
With the same input the user can establish and finish the program
connection (call when the input is activated, hang-up when it is
deactivated). The destination address should be selected from the
book.
Talkback Call/Hang-Up
With the same input the user can establish and finish the talkback
connection (call when the input is activated, hang-up when it is
deactivated). The destination address should be selected from the
book.
Reboot
Allows the user to reboot the unit upon the activation of a GPI.
Disable Fan
This control enables or disables the internal FAN
Load Preset
Allows the user to load a preset upon the activation of a GPI.
Acknowledge Alarms
When this input is activated, the alarms will be acknowledged.
Program Call
When this input is activated, the codec will proceed automatically
to connect the Program (codec 1) line. The user can select which
entry of the book will be used for this purpose.
Program Hang-up
When this input is activated, the codec will proceed automatically
to disconnect Program (codec 1) line.
Talkback Call
When this input is activated, the codec will proceed automatically
to connect the Talkback (codec 2) line. The user can select which
entry of the book will be used for this purpose.
Talkback Hang-up
When this input is activated, the codec will proceed automatically
to disconnect Talkback (codec 2) line.
