2. INSTALLATION
2.1 Receiver:
1. connect the receiver with the telephone by attaching one side of the spiral cable to
the bottom of the receiver and the other side to the left side of the telephone (See
illustration on previous page)
2. push in the plugs until they’re securely connected
2.2 Telephone:
1. plug the telephone wire into the bottom of the telephone
2. insert the telephone plug into a telephone wall socket
2.3 Desk bracket:
you can use the phone as a desk model by
clicking the bracket onto the bottom of the
phone according to the illustration below
press the bracket according to
the illustration to disassemble again
2.4 Wall-mounting:
1. in a vertical line, drill 2 holes at a distance of 10 cm from each other and insert plugs
and screws; let the head of the screws protrude for 5 mm
2. rotate the receiver suspension tab 180° according to
the picture; this tab will hold the receiver when used
in a suspended position
3. hook the telephone with the screw holes over the screws and
press it downward
4. x the phone line with cable-ties onto the wall
