7
1
. Make sure that the power cord is unplugged.
W
ith the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (48) so that the treadmill is more stable;
do not fully fold the Frame yet.
Cut the tie securing the Wire Harness (77) to the
Base (85). Next, locate a tie in the indicated hole
in the Base, and use the tie to pull the Wire
Harness out of the hole.
8
5
48
1
77
Hole
2. Attach two Base Feet (81) to the Base (85) in
the locations shown with two M4.2 x 25mm Tek
Screws (2) and two Base Pad Spacers (74).
Attach the other two Base Feet (81) with only
two M4.2 x 25mm Tek Screws (2).
85
2
81
2
81
2
2
81
2
81
74
74
To Next Page
