ProForm 575 - Page 18

PART LIST—Model No. PETL57510 R0501A
1 2 Handrail
2 1 Key/Clip
3 6 Long Screw
4 1 Battery Cover
5 2 Foot Rail
6 1 Lift Motor
7 2 Incline Leg Bolt
8 1 Speed Potentiometer
9 1 Speed Control Knob
10* 1 Console Assembly
11 1 Upright
12 1 Motor Belt
13 2 Cable Tie Screw
14 1 Storage Latch
15 1 Pulse Bar
16 7 8” Cable Tie
17 1 Motor Swivel Nut
18 1 Pulley/Flywheel/Fan
19 1 Motor
20* 1 Motor/Pulley/
Flywheel/Fan
21 1 Wire Harness
22 1 Foam Block
23 1 Motor Hood
24 1 Hood Shield
25 16 Small Screw
26 1 Controller
27 1 Motor Swivel Bolt
28 1 Motor Tension Nut
29 1 Motor Tension Star
Washer
30 1 Motor Tension
Washer
31 2 Motor Tension Bolt/
Leg Bolt
32 1 Incline Stop Bracket
33 9 Reed Switch Screw/
Hood Screw
34 2 Extension Leg
35 1 Allen Wrench
36 2 Wheel Bolt
37 2 Wheel
38 6 Wheel Nut/Lift Nut
39 15 Washer
40 4 Base Pad
41 2 Handrail Endcap
42 1 Catch
43 1 Reed Switch Clip
44 1 Reed Switch
45 1 Magnet
46 1 Console Base
47 2 Frame Pivot Spacer
48 4 Platform Screw
49 4 Isolator
50 1 Front Roller/Pulley
51 1 Front Roller Adj. Bolt
52 2 Incline Wheel
53 2 Extension Leg Screw
54 2 Rear Isolator Screw
55 1 Receptacle
56 1 Circuit Breaker
57 2 Frame Pivot Washer
58 2 Frame Pivot Bolt
59 1 Grounding Screw
60 1 Motor Belly Pan
61 4 Cable Tie Clamp
62 2 Rear Platform Screw
63 3 Releasable Tie
64 1 Choke
65 2 Belt Guide
66 2 1/2” CLamp
67 1 Walking Belt
68 1 Walking Platform
69 1 Belly Pan
70 17 Electronics Screw
71 1 Incline Wire Harness
72 2 Rear Isolator
73 4 Isolator Screw
74 2 Handrail Bolt
75 4 Handrail Washer
76 1 Left Front Endcap
77 2 Incline Wheel Bolt
78 1 Right Front Endcap
79 4 Incline Wheel Nut
80 1 Ground Wire
81 1 Stop Bracket Bolt
82 1 Incline Leg
83 2 Rear Roller Adj. Bolt
84 1 Rear Endcap
85 1 Latch Decal
86 1 Rear Roller
87 1 Frame
88 2 Pulse Bar Bolt
89 1 Grounding Washer
90 4 Nylon Washer
91 1 Grounding Nut
92 1 Electronic Bracket
93 2 Motor Pivot Bushing
94 1 Motor Pivot Sleeve
95 1 Filter
96 4 Upright Grommet
97 1 25” Control/Pulse
Wire
98 1 Power Cord Set
99 14 Console Screw/
Endcap Screw
100 4 Guide Belt Screw
101 2 Latch Screw
102* 2 Base Leg Assembly
# 2 8” Green Wire F/Ring
# 1 4” Black Wire, 2 F
# 1 4” White Wire, 2F
# 1 4” Green Wire, F/ring
# 1 4” Black Wire, M/F
# 1 8” White Wire, Pigtail
# 1 User’s Manual
* Includes all parts shown in the
box.
# These parts are not illustrated.
